4E30YD
The products are well known all over the country and exported to many foreign countries such as Southeast Asia, American and European countries, etc.
Availability:
Inquire
DOWNLOAD
MAIN TECHNICAL PARAMETERS
TECHNICAL PARAMETERS
Type
4E30YD
Aspiration
Supercharge
Displacement(L)
3
Bore(mm)xStroke(mm)
94x107
Power(kW)
48
Fuel Injection System
Common Rail
Fuel consume rate (g/kW-h)
210
Noise dB(A)
≤105
Emission level
CN stage II
Weight (kg)
280
Dimensions (mm)
750x580x790
Engine
Type
In-line, water cooled, 4-stroke, direct injection ring-like platform combustion
Speed [min-1]
1500
Exhaust emission standard
CN stage IV
General
Aspiration
Supercharge
No. of cylinders
4
Compression ratio
17.5
Rotation (looking at flywheel)
Counter clockwise
No. of teeth on flywheel ring gear
118
Governing standards
Speed droop (static) mech. gov.[%]
-
Speed droop (static) electr. gov. (EMR/GAC)[%]
3
Lubrication system
Oil specification
CH
Oil consumption (as % of fuel consumption)
0.2
Oil pan capacity[l]
6.5
Output
Fan reduction [kW]
3
Net flywheel [kW]
45
Electrical output
50
Fuel System
Fuel consumption
25% load[l/h]
250
50% load [l/h]
237
75% load [l/h]
226
100% load [l/h]
225
Cooling System
General engine cooling data
Max. perm. coolant outlet temperature [°C]
102
Coolant capacity (engine) [l]
5.8
Air to boil (max. permissible cool. air temp. at fan) [°C]
45
Cooling air flow [m3/h]
252
Air pressure loss [bar]
0.04
Electrical System
Voltage[V]
12
Starter [kW]
2.5
Alternator output [A]
70
Type
4E30YD
Aspiration
Supercharge
Displacement(L)
3
Bore(mm)xStroke(mm)
94x107
Power(kW)
48
Fuel Injection System
Common Rail
Fuel consume rate (g/kW-h)
210
Noise dB(A)
≤105
Emission level
CN stage II
Weight (kg)
280
Dimensions (mm)
750x580x790
Engine
Type
In-line, water cooled, 4-stroke, direct injection ring-like platform combustion
Speed [min-1]
1500
Exhaust emission standard
CN stage IV
General
Aspiration
Supercharge
No. of cylinders
4
Compression ratio
17.5
Rotation (looking at flywheel)
Counter clockwise
No. of teeth on flywheel ring gear
118
Governing standards
Speed droop (static) mech. gov.[%]
-
Speed droop (static) electr. gov. (EMR/GAC)[%]
3
Lubrication system
Oil specification
CH
Oil consumption (as % of fuel consumption)
0.2
Oil pan capacity[l]
6.5
Output
Fan reduction [kW]
3
Net flywheel [kW]
45
Electrical output
50
Fuel System
Fuel consumption
25% load[l/h]
250
50% load [l/h]
237
75% load [l/h]
226
100% load [l/h]
225
Cooling System
General engine cooling data
Max. perm. coolant outlet temperature [°C]
102
Coolant capacity (engine) [l]
5.8
Air to boil (max. permissible cool. air temp. at fan) [°C]
45
Cooling air flow [m3/h]
252
Air pressure loss [bar]
0.04
Electrical System
Voltage[V]
12
Starter [kW]
2.5
Alternator output [A]
70
